Brand | Gigabyte |
Model | B760M |
SOCKET | LGA1700 |
Chipset | Intel B760M |
Memory | |
Memory Slot | 4 |
Memory Type | DDR5 |
Max. Capacity | 128GB |
Speed | 4000 , 4800 , 5200 (OC) , 5400 (OC) , 5600 (OC) , 5800 (OC) , 6000 (OC) , 6200 (OC) , 6400 (OC) , 6600 (OC) , 6800 (OC) , 7000 (OC) , 7200 (OC) , 7400 (OC) , 7600 (OC) |
Graphic | Integrated Graphics Processor (Depends on CPU) |
Storage | |
SATA 3 | 4 Port |
M.2 | 2 x M.2 Connector(s) |
Raid | RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices |
Network | |
LAN | Realtek 2.5Gb Ethernet |
LAN Speed | 100/1000/2500 Mbps |
Wireless | - |
Ports | |
USB 2.0 | 5 Port |
USB 3.2 | 3 x USB 3.2 Gen 1 Type-A Port |
HDMI | 1 Port |
DisplayPort | 1 Port |
Audio | 3 Port |
Form Factor | M-ATX |
Power Connector | |
CPU | 8 Pin |
Mainboard | 24 Pin |
