| Brand | Galax |
| Model | RTX 5080 1-CLICK OC WHITE |
| DIMENSIONS | 315 x 140.5 x 50.7mm |
| Port Connector | |
| HDMI Port | 2.1b x 1 |
| Display Port | 2.1b x 3 |
| Specification | |
| Slot | PCI-E 5.0 |
| Chipset | Nvidia |
| Series | Nvidia GeForce 50 Series |
| GPU Model | GeForce RTX 5080 |
| PROCESSOR CLOCK SPEED | Boost Clock: 2625MHz 1-Click OC Clock: 2640MHz (by installing Xtreme Tuner Plus Software and using 1-Click OC) |
| MEMORY | 16GB |
| MEMORY SPEED | 30 Gbps |
| MEMORY TECHNOLOGY | GDDR7 |
| COOLING TYPE | Air cooling 3 Fan |
| Bus Width | 256-bit |
| CUDA CORE | 10752 |
| Max Resulution | 7680 x 4320 |
| DirectX | 12 Ultimate |
| Power Requirement | |
| Maximum Graphics Card Power | ±360 W |
| Need Power Supply | 850 W |
| Power Connectors | 1 x 16 Pin or 3 x 8 Pin |
